Cummins C66D5EQ Diesel Generator

£11,199.00 Excluding VAT

Cummins C66D5EQ Generator Specifications

Standby Power Rating: 66 kVA / 53 kW
Prime Power Rating: 60 kVA / 48 kW
Engine: Cummins 4BTAA3.3-G14 (Stage IIIa)
Engine Governor: Mechanical
Engine Speed: 1500 rpm
Alternator: Stamford UC224F
Voltage: 400V
Frequency: 50Hz
Amps Per Phase: 95.4
Control Panel: PS0600
Connection Type: Circuit Breaker
Circuit Breaker: 4-Pole
Exhaust Emissions Level: Stage IIIa
Base Fuel Tank Capacity: 200 Litres
Fuel Consumption: 14 litres per hour (at 100% load)
Dimensions (L x W x H): 2315mm x 1015mm x 1685mm
Dry Weight: 1,282kg
Canopy Noise Level: 75 dB(A) at 1m / 64 dB(A) at 7m
Additional Features: Battery Charger, Water Heater
Warranty: 2 years or 500 hours standby / 1 year unlimited hours prime

Description

Cummins C66D5EQ Generator

Overview

The Cummins C66D5EQ is a 66 kVA, three-phase, auto-start, 50Hz silent diesel generator, equipped with the reliable Cummins 4BTAA3.3-G14 engine and the Stamford UC224F alternator.

Building on over a century of expertise, the new Cummins C66D5EQ delivers the quality and reliability synonymous with Cummins gensets, now with enhanced versatility in a lighter, more compact design. Its innovative exterior is designed to be stackable, making storage simpler and more cost-effective.

The rugged Cummins 4BTAA3.3-G14 4-cycle industrial Stage IIIa diesel engine and Stamford UC224F alternator are managed by the PS0600 microprocessor-based control system. This system monitors critical engine and alternator functions, provides digital genset metering, component protection, utility voltage monitoring and protection, configurable start and stop time delays, and more.

Manufactured in Europe to meet the region’s evolving power requirements, the Cummins Q Range C66D5EQ is fully certified with CE and UKCA compliance.

Key Features

mmins C66D5EQ generator is a po

werful and efficient power solution designed to meet the needs of various applications. With its advanced features and durable construction, this generator ensures reliable performance and long-lasting service in any envi

Reliable Power Output

The C66D5EQ delivers a dependable power output of 66 kVA, making it suitable for both prime and standby power applications. Its consistent performance ensures uninterrupted operation, reducing downtime and increasing productivity.

Advanced Control System

Equipped with the PowerCommand® 2.3 control system, the C66D5EQ offers precise monitoring and control of generator functions. The intuitive interface allows for easy operation and seamless integration with existing systems.

Quiet Operation

With advanced sound attenuation technology, the C66D5EQ operates quietly, making it ideal for noise-sensitive environments. Whether in residential areas or urban settings, this generator provides power without disruption.

Durability and Longevity

Constructed with high-quality components and a rugged design, the C66D5EQ is built for durability and longevity. It can withstand harsh conditions and continuous operation, ensuring reliable performance in any situation.

Specifications

Standby Power Rating: 66 kVA / 53 kW
Prime Power Rating: 60 kVA / 48 kW
Engine: Cummins 4BTAA3.3-G14 (Stage IIIa)
Engine Governor: Mechanical
Engine Speed: 1500 rpm
Alternator: Stamford UC224F
Voltage: 400V
Frequency: 50Hz
Amps Per Phase: 95.4
Control Panel: PS0600
Connection Type: Circuit Breaker
Circuit Breaker: 4-Pole
Exhaust Emissions Level: Stage IIIa
Base Fuel Tank Capacity: 200 Litres
Fuel Consumption: 14 litres per hour (at 100% load)
Dimensions (L x W x H): 2315mm x 1015mm x 1685mm
Dry Weight: 1,282kg
Canopy Noise Level: 75 dB(A) at 1m / 64 dB(A) at 7m
Additional Features: Battery Charger, Water Heater
Warranty: 2 years or 500 hours standby / 1 year unlimited hours prime

Applications

Applications:

  • Agriculture
  • Commercial Industrial
  • Construction
  • Healthcare
  • Prime Power
  • Residential Home Standby
  • Small Business Standby
  • Standby Power

Commercial and Industrial

The C66D5EQ is ideal for commercial and industrial applications, providing reliable power for offices, shops, and medium-sized businesses. Its compact design and quiet operation make it versatile for various environments.

Standby Power

As a standby power solution, the C66D5EQ ensures uninterrupted operation during power outages. Whether for critical infrastructure or essential services, this generator provides peace of mind and reliability.

Events and Entertainment

With its portable design and quiet operation, the C66D5EQ is perfect for outdoor events and entertainment venues. It provides power for lighting, sound systems, and equipment, enhancing the overall experience for attendees.

Benefits

Easy Installation

The C66D5EQ is designed for easy installation and setup, minimizing installation time and costs. Its compact footprint and flexible mounting options make it suitable for a wide range of installation environments.

Low Maintenance

With accessible service points and durable components, the C66D5EQ requires minimal maintenance, reducing overall operating costs. Routine servicing is straightforward, ensuring the generator remains in top condition.

Global Support

As a Cummins generator, the C66D5EQ is backed by a worldwide network of service centers and support teams. Wherever you are, you can rely on Cummins for expert assistance and reliable service.

For full data sheet visit Cummins Generator Sets | Fully Integrated Power

If you require any more info please feel free to contact us Contact Us – GWF Generators (gwfenergy.co.uk)
